Quick Opening Closure Automated Pigging System Pipeline Launcher And Receiver
| Place of Origin | Beijing, China |
|---|---|
| Brand Name | Beijing VP Co., Ltd |
| Certification | ISO Certificate; 3A Certificate |
| Model Number | Customized according to demand |
| Minimum Order Quantity | 1 |
| Payment Terms | T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | WCB,CF8,CF8M,Alloy | Pressure Standard | ANSI 150# |
|---|---|---|---|
| Opening Type | Vertical/Horizontal | Seals | NBR, FKM, PTFE, AU, VMQ, EPDM (other Materials On Request) |
| Port Type | ASME B16.5 RF | Showroom Location | None |
| Highlight | Quick Opening Closure Automated Pigging,pipeline launcher and receiver,Pipeline Automated Pigging System |
||
Product Description
Quick Opening Closure - Best Services - BJVP - Automated Pigging System
Overview:
We aim to develope products and advanced services as completely integrated turnkey solutions for your needs. BJVP Quick Opening Closures offers the most strong and safely products in the world.
Our high pressure Quick Opening Closures are designed, engineered and manufactured as per strict international requirements which are applicable to the Pressure Vessels for Oil, Gas, Petrochemical, Waste water treatment and Marine industry. We are providing our best services for entire device determining life time accurately as well as longest durability by our in-house engineering services.
Characteristics:
The following functions can be realized through Pigging
- Optimal use of resources
- Increase yields
- High-accuracy pipe Pigging System
- Reduce flush waste
- Save time and money
- Reduce contamination risks, free of residual
- Changeable lips of pig can minimize the cost of consumer.
- Increased economic efficiency in production
Parameters:
|
Port Type |
ASME B16.5 RF |
| Pipe Size | 1.5”~8” |
| Pressure Standard | ANSI 150# |
| Material | WCB,CF8,CF8M,Alloy |
| Liquid Viscosity | 0.1～440,000 cst |
| Liquid Temperature | -52～380℃ |
| Product Category |
ASME B16.5 RF Launcher Receiver Pig Stop T-way valve Three-way distribution valve 5D elbows Pig Pigging line Electric cabinet Control System |
Pictures:
Applications:
- Chemical product
- Pier location product
- Manual & automatic control
- Pigging relevant accessories.
F&Q:
Q1: What can pigging system do in pipeline?
A: BJVP Pigging System can use the pig to clean the pipe line. There is no redidue and contamination between the different kind of liquid sharing the same pipe.
Q2: What is pigging equipment?
A: BJVP pigging equipment includes items such as high finishing pipe Pigging System, pig launcher/ receiver, middle station, pig detectors, pig, etc.
Q3: Where can this pigging system be used?
A: BJVP pigging equipment can be widely used in Lubricants and greases, paints and varnishes, special chemicals, perfumes and other industry applications.
Q4: How do pigs clean the pipelines?
A: Pig is pushed by forced air from the launcher to receiver, so the product and any residues in pipeline will be pushed out of the pipeline by pig.
