Automatic IBC Decanting System 6-10 M3/H Unloading Speed
| Brand Name | Beijing VP |
|---|---|
| Model Number | Customized according to demand |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Standard Barrel Capacity | 200L Barrel/IBC | Empty Bucket Residual Amount | Less Than 0.5kg After Rinsing 200L Drum |
|---|---|---|---|
| Unloading Speed | 6-10 M3/h | Full Time In Automatic Mode | Less Than 6 Min/drum |
| System Pressure | 16bar | Temperature Range | 40℃~130℃ |
| Viscosity Range | Up To 2,000 Cps | ||
| High Light | Automatic IBC Decanting System,IBC Decanting System,Auto IBC Decanting System |
||
Product Description
Automatic IBC Decanting System 6-10 M3/H Unloading Speed
Characteristics:
VP Drum Decanting Unit is an automatic decanting system for high viscosity additives. The equipment is designed to perform quantitative decanting in drum, rinsing empty drum and empty the drum. The weighing system can be tilted and lance to track the liquid level during decanting.
Decanting and Rinsing data can be set at site. The control can be set to Automatic or Manual mode.
High efficient decanting process, zero leakage and no contamination.
Working Scope:
| Standard barrel capacity | 200L barrel/IBC |
| Empty bucket residual amount | less than 0.5kg after rinsing 200L drum |
| Unloading speed | 6-10 m3/h |
| Full time in automatic mode | less than 6 min/drum |
| System pressure | 16bar |
| Temperature range | 40℃~130℃ |
| Viscosity range | Up to 2,000 cps |
| Lance |
Bottom Valve, 3 level for decanting/rinsing/close. Lance can trace liquid level automatically. |
| Control system | DDU can operate from the HMI and communicate with the DCS |
| Field display | Input parameters, real-time display of weight of rinsing tank and additives, alarm indicator, emergency stop button |
| Rinsing oil tank | with heating jacket and insulation |
| Gross weight | about 2550 kg |
